XM Series Distribution Box Housing Configuration

The XM Series Distribution Box features a robust, modular housing made from high-quality steel or flame-retardant materials, designed for safe, flexible, and efficient low-voltage power distribution.

Construction and Materials

The X

M Series distribution box is typically constructed from high-quality cold-rolled steel or stainless steel plates, often with electrostatic powder coating for durability and corrosion resistance. Some models use flame-retardant plastics for lightweight and fire safety considerations. The housing is designed to withstand environmental factors such as moisture, dust, and corrosion, making it suitable for both indoor and outdoor installations.

Weatherproof models are available with IP65 or higher ratings for protection against water ingress and dust.

Design Features

Modular Layout: The housing accommodates multiple circuit breakers, residual current devices (RCDs), fuses, and busbars, allowing for easy expansion or reconfiguration as power needs change.

Compact and Space-

Efficient: Despite its capacity, the XM housing is designed to save space in electrical rooms or panels, with a clear and organized layout for maintenance and troubleshooting. Safety Compliance: The housing meets international standards such as IEC 61439 and UL 508A, featuring insulated busbars, secure terminal connections, and clear labeling to prevent electrical hazards.

Electrical Specifications

Rated Voltage: 220V/380V ACRated Current: Up to 400A for industrial models, and ≤100A for indoor lighting models Frequency: 50HzSystem Compatibility: Suitable for three-phase four-wire power systems ApplicationsThe XM Series housing is widely used in: Residential buildings: Main panels for lighting, outlets, and appliances Commercial and office buildings: Power distribution and meteringIndustrial plants and factories: Motor loads, lighting, and control circuitsHospitals and workshops: Reliable low-voltage distribution with overload and short-circuit protection Installation OptionsSurface-mounted on walls or panelsFlush-mounted within walls for a cleaner appearanceSuitable for environments with ambient temperatures from -5°C to +40°C, relative humidity up to 90% (non-condensing), and altitudes ≤2000m Additional FeaturesOverload, short-circuit, and leakage protectionFlexible electrical schemes for customized configurationsQuick maintenance access due to clear labeling and organized internal layout The XM Series Distribution Box housing combines durability, safety, and modularity, making it a versatile solution for low-voltage power distribution across residential, commercial, and industrial applications.
