Metal brackets for roof cable trays

Roof top cable supports offer an economical and time saving solution for mounting cable and basket trays onto flat roofs. Products can be used for individual installations or combined to support complete roof plant installations. Our range includes:​ Stand-Off Brackets: Ideal for mounting cable trays or baskets with a specific clearance from. The Roof-Pro range of cable management solutions is suitable for supporting the following: For smaller cable volumes, Roof-Pro's TAB-C support utilises a single, broad base that provides effective and non-penetrative support for tray and ladder runs. Cable supports are manufactured according to common standards from high quality raw materials.
