Fiber Optic Cable Connector Model and Specification Table

Common fiber optic connectors include SC, LC, ST, FC, and MPO/MTP, each with distinct ferrule sizes, polishing types, and applications.

Fiber Optic Connector Specification Table

Connector Type

Ferrule SizePolishing TypeInsertion LossReturn LossDurabilityTypical ApplicationsNotesSC (Subscriber Connector)2. 5 mmUPC / APC≤0. 3 dBUPC ≥50 dB, APC ≥60 dB≥1,000 mating cyclesFTTH, data centers, telecom backbonePush-pull latching, simplex/duplex optionsLC (Lucent Connector)1.

25 mmUPC / APC≤0. 3 dBUPC ≥50 dB, APC ≥60 dB≥1,000 mating cyclesHigh-density data centers, SFP/SFP+ transceiversSmall form factor, latch mechanismST (Straight Tip)2. 5 mmUPC≤0.

3 dB≥50 dB≥1,000 mating cyclesLegacy networks, multimode fiberBayonet twist-lock couplingFC (Ferrule Connector)2. 5 mmUPC / APC≤0. 3 dBUPC ≥50 dB, APC ≥60 dB≥1,000 mating cyclesHigh-vibration environments, single-mode fiberScrew-on coupling, precise alignmentMPO / MTP (Multi-Fiber Push-On)0.

8 mm per fiberUPC / APC≤0. 35 dBUPC ≥50 dB, APC ≥60 dB≥1,000 mating cyclesData centers, high-density fiber arraysMulti-fiber (12/24 fibers), push-pullMU (Miniature Unit)1. 25 mmUPC / APC≤0.

3 dBUPC ≥50 dB, APC ≥60 dB≥1,000 mating cyclesHigh-density telecomSmall form factor, duplexE20001. 25 mmAPC≤0. 2 dB≥60 dB≥1,000 mating cyclesTelecom, high-performance networksSpring-loaded shutter for dust protectionMTRJ1.

25 mmUPC≤0. 3 dB≥50 dB≥1,000 mating cyclesLANs, patch cordsDuplex, small form factorKey ConsiderationsPolishing Types: UPC (Ultra Physical Contact): Flat ferrule, low reflection, general use.

AP

C (Angled Physical Contact): 8° angle ferrule, very low reflection, ideal for RF video and GPON networks. Color Coding: APC connectors: GreenUPC connectors: BlueFiber Compatibility: Single-mode connectors are optimized for single-mode fibers, while multimode connectors are used with multimode fibers. Many connectors, such as SC, LC, and FC, are compatible with both types.

Durability: Most connectors are rated for ≥1,000 mating cycles without performance degradation. Applications: Selection depends on network density, fiber type, and environmental conditions, such as vibration or space constraints. This table provides a comprehensive reference for selecting fiber optic connectors based on technical specifications, performance, and application requirements.
