Huijue Cable Tray Model Specifications Table

Huijue offers a range of commercial and industrial cable trays, including ladder, perforated, and solid-bottom types, designed for versatile electrical installations.

Overview of Huijue Cable Tray Series

Huijue Group, founded in 2002, specializes in intelligent network and energy storage equipment, exporting products globally, including cable management solutions. Their cable trays are designed for commercial and industrial applications, providing secure support and protection for electrical cables. Main ModelsLadder-Type Cable TraysFeature side rails with rungs for maximum ventilation and heat dissipation.

Suitable for heavy-duty cabling and long cable runs. Allow easy installation and maintenance of large bundles of cables.

Perforated or Ventilated Trays

Solid base with perforations to allow airflow and reduce heat accumulation. Ideal for medium-load applications where cable cooling is important.

Solid-

Bottom Trays

Fully enclosed base for maximum protection against dust, moisture, and mechanical damage. Commonly used in sensitive environments or outdoor installations. Materials and FinishesPre-galvanized steel for standard durability.

Hot-dip galvanized steel for enhanced corrosion resistance. Aluminum for lightweight and non-corrosive applications. Custom coatings may be available for specific environmental or fire-rated requirements.

Specifications

Widths: Typically range from 100 mm to 600 mm, depending on model and load requirements. Side Rail Heights: Vary from 50 mm to 150 mm for ladder and perforated trays. Load Capacity: Designed to support light to heavy cable loads; exact ratings depend on tray width, material, and span between supports.

Standards Compliance: Huijue trays are manufactured to meet international standards for structural integrity and safety, suitable for both indoor and outdoor installations.

Accessories and Customization

Fittings: Elbows, tees, reducers, and couplers for flexible routing. Supports: Wall brackets, ceiling hangers, and floor stands. Customization: Huijue can provide tailored solutions for unusual layouts, high-volume cable runs, or specific regulatory requirements.

Datasheets

While some datasheets for Huijue tray-type cable trays are limited online, they typically include part numbers, dimensions, material types, and load ratings. For precise specifications, contacting Huijue directly or accessing their official product catalog is recommended.

Summary

Huijue cable trays provide versatile, durable, and customizable solutions for commercial and industrial cable management. Their product range includes ladder, perforated, and solid-bottom trays, available in steel or aluminum, with a variety of widths, side heights, and load capacities. Accessories and custom options allow adaptation to complex installations, ensuring compliance with international standards and long-term reliability.
