Function of cable tray tension fixing bracket

A cable tray tension fixing bracket secures cable trays to supporting structures, maintaining alignment, stability, and resistance to mechanical forces.

Primary Function

A cable tray tension fixing bracket is a support element used to mechanically secure cable trays to ceilings, walls, floors, or structural beams, ensuring that the trays remain stable under the weight of cables and external forces such as wind, vibration, or short-circuit events. It prevents unwanted movement, sagging, or misalignment of the tray system, which could compromise cable integrity or safety.

Load and Force Management

The bracket is designed to withstand mechanical loads generated by the cables themselves and additional environmental forces. In particular, during a short circuit, cables can exert significant lateral and vertical forces, and the tension fixing bracket restrains these forces to prevent structural failure or cable damage. It also helps maintain the minimum bend radius for cables, avoiding stress or deformation that could affect performance.

Installation and Support

Tension fixing brackets are typically installed near joints, bends, or changes in direction of the cable tray to provide extra support where mechanical stress is highest. They can be used in combination with cantilever, pendant, or wall-mounted brackets, and may include threaded rods or adapters to attach securely to the building structure. Proper spacing and alignment of these brackets are critical to ensure the overall stability and safety of the cable tray system.

Additional Benefits

Maintains cable organization by keeping trays aligned and preventing sagging. Enhances safety by reducing the risk of cable damage or electrical hazards. Supports compliance with standards such as DIN EN 61537 and BS EN 61537, which govern cable support systems.

In summary, a cable tray tension fixing bracket is an essential component that ensures the mechanical stability, safety, and proper functioning of cable tray installations, particularly in industrial or high-load environments.
