Quick Fixing of Cable Tray Cover Plates

You can quickly fix cable tray cover plates using pressing plates, screws, clamps, or specialized cover clamps depending on the tray type and installation orientation.

Common Fastening Methods

Pressing Plate Fixing Punch holes in the cover plate, place a pressing plate over it, and secure with screws. This method works for both horizontal and vertical installations and provides strong, reliable fastening. Screw Fastening Pre-punch the cover plate and use screws or rotating plate buckles to attach it to the tray.

This method is suitable for quick, secure installation in any orientation. Buckle Fixing Bend the folds at both ends of the buckle to hold the cover plate. This is faster since no punching is required, but it is best for horizontal installations as vertical setups may allow the cover to slip.

Padlock or Seven-

Shaped Buckle Fixing These methods provide additional security for high-demand environments or outdoor installations, preventing accidental dislodging. Specialized Cover Clamps (PKP-SP Series) For perforated or mesh cable trays, PKP-SP1, PKP-SP2, and PKP-SPM1 clamps allow mechanical fastening. Some clamps require screws, while others are tool-free, enabling very fast installation even in vertical or windy conditions.

Quick Installation Tips

Use pre-drilled holes whenever possible to save time. Select the appropriate clamp or screw type based on tray material (metal, mesh, or perforated). Ensure alignment of the cover plate with the tray edges before fastening to avoid gaps.

For T-joints or elbows, use brackets and bolts designed for rapid assembly to reduce installation time. Check stability after installation, especially for vertical trays or areas exposed to vibration or wind. By choosing the right method and tools, you can secure cable tray cover plates efficiently while maintaining safety and durability.
