Reasons why low-voltage cables don t need to be run in cable trays

Fiber and communications infrastructure knowledge brief Published 06 Sep 2024

Use this reference to prepare product questions for CJC FIBRE. Check interfaces, capacity, protection and installation requirements against the current product documentation.

Failing to run low-voltage cables in cable trays can lead to safety hazards, code violations, signal interference, and maintenance difficulties. Safety and Physical DamageLow-voltage cables that are not installed in cable trays are more susceptible to physical damage from foot traffic, equipment, or accidental impacts, which can compromise insulation and create fire hazards or short circuits. Cable trays provide a secure pathway that keeps cables organized, supported, and protected from mechanical stress.

Code Compliance

The National Electrical Code (NEC) specifies installation requirements for low-voltage and communication cables, including proper support, spacing, and separation from higher-voltage circuits. Not using cable trays may result in non-compliance with NEC Articles 645, 725, 770, 800, and 810, potentially leading to failed inspections or legal liability. Electromagnetic Interference (EMI)Low-voltage signal and communication cables are sensitive to electromagnetic interference from nearby power cables.

Cable trays allow for segregation of power and signal cables, maintaining at least 12 inches of vertical separation or using barriers to prevent interference. Without trays, signal degradation, data errors, or control system malfunctions may occur, especially near variable frequency drives (VFDs) or high-current circuits.

Maintenance and Accessibility

Cable trays provide organized routing and easy access for installation, inspection, and maintenance. Without trays, cables may be tangled, difficult to trace, or require dismantling other systems to access, increasing labor costs and downtime.

Voltage Separation

For low-voltage cables sharing space with higher-voltage circuits, cable trays help enforce proper separation.

NE

C 392. 20 requires that cables rated over 600 volts be separated from those rated 600 volts or less, either by barriers or separate trays. Ignoring this can create safety risks and code violations.

Summary

Not using cable trays for low-voltage cables can result in: Increased risk of physical damage and fire hazardsNon-compliance with NEC and other standardsSignal interference and degraded performanceDifficult maintenance and cable management issuesImproper voltage separation, increasing safety risks Proper cable tray installation ensures safety, reliability, and regulatory compliance for low-voltage systems.
