Huawei Switch Access Ports

Fiber and communications infrastructure knowledge brief Published 06 Dec 2024

Use this reference to prepare product questions for CJC FIBRE. Check interfaces, capacity, protection and installation requirements against the current product documentation.

Huawei switches feature various ports that can be configured for different network functions, including access and trunk ports, VLAN management, and security settings. Types of Ports on Huawei SwitchesAccess Ports: These ports are used to connect end devices like computers and printers to the network. They typically belong to a single VLAN and are configured to carry traffic for that VLAN only.

To configure an access port, you would use commands like:interface GigabitEthernet 0/0/1 (replace with your port ID)port link-type accessport default vlan 10 (assigning VLAN 10). Trunk Ports: Trunk ports are used to connect switches to each other and can carry traffic for multiple VLANs. They are configured to allow VLAN tagging, which helps in identifying the VLAN of the traffic.

To configure a trunk port, you would use:interface GigabitEthernet 0/0/2 (replace with your port ID)port link-type trunkport trunk allow-pass vlan 10 20 30 (allowing VLANs 10, 20, and 30).

Configuring Ports

To enable and configure ports on a Huawei switch, follow these steps: Access the CLI: Connect to the switch using SSH or a console cable and log in. Enter Configuration Mode: Use the command system-view to enter configuration mode. Select the Port: Navigate to the desired port using interface GigabitEthernet 0/0/1 (replace with your port ID).

Enable the Port: Activate the port with the command undo shutdown.

Assign VLA

Ns: For access ports, assign a VLAN using port link-type access and port default vlan. Save Configuration: Always save your changes with the save command to ensure they persist after a reboot.

Security Considerations

When configuring ports, it's essential to implement security measures to prevent unauthorized access. This includes: Port Security: Enable port security features to restrict access based on MAC addresses. Rate Limiting: Use commands like qos lr outbound cir to prevent traffic floods.

Access Control Lists (ACLs): Implement ACLs to filter traffic and enhance security. By understanding the types of ports and how to configure them, you can effectively manage your Huawei switch and ensure a secure and efficient network environment.
